BALL RUNNER BLOCK CARBON STEEL KWD-030-FLS-C2-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FLS-C2-H-1 (R165372320) is a high-precision ball runner block designed for linear motion applications requiring superior rigidity, accuracy, and dynamic characteristics. This model features a size 30 flange width, long length, and standard height configuration, crafted from unalloyed steel CS to ensure durability and performance. The runner block boasts a medium preload (Preload class C) and high accuracy (Accuracy class H), without the inclusion of a ball chain. The B.RUNNER BLOCK CS is prelubricated with Roller bearing grease Dynalub for reduced maintenance needs and comes equipped with initial lubrication and preservation for longevity. It does not include attachment elements on either the left or right front reference edges but does have a straight lube connection that is loosely attached for convenience. With an overall length of . mm, this runner block can be combined with guide rails of any accuracy level due to its interchangeability feature. It excels in applications with stringent rigidity requirements, offering significantly reduced frictional oscillations and low friction levels even under external loads. Its patented entry zone enhances travel accuracy by up to six times. Designed for long-term lubrication over several years, this model includes lube fittings with metal threads on all sides and an end-face fastening thread for versatile attachments. The integrated all-around sealing provides protection against contaminants, contributing to the high torque load capacity of the system. Furthermore, the B.RUNNER BLOCK CS can support applications using just one runner block per rail due to its high rigidity in all load directions. The two additional mounting screw holes at the center enhance stability under liftoff and side loading conditions. Optional features include an integrated inductive measuring system for precise feedback. This Bosch Rexroth ball runner block is compatible with all SN/SNO ball guide rails and maintains high load ratings across four main loading directions. Pre-lubricated at the factory, it offers ease of installation and immediate operation within permissible ambient temperatures ranging from min ... max °C.
