BALL RUNNER BLOCK CARBON STEEL KWD-030-FLS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-FLS-C1-N-1 (R165371423) is a high precision ball runner block designed for linear motion systems. It features a size 30 flanged long standard (FLS) block made of unalloyed steel CS, with a low preload class C and standard accuracy class N. The runner block comes with a ball chain that ensures low noise operation and optimal travel behavior. Its dynamic characteristics are enhanced by the patented entry zone, which can increase travel accuracy by up to six times. This runner block is capable of long-term lubrication lasting several years and includes initial lubrication and preservation for immediate use. It's equipped with lube fittings that have metal threads on all sides, ensuring easy maintenance and re-lubrication. The overall length of the runner block is specifically designed for compatibility with different preload classes, providing high rigidity in all load directions which allows for applications using just one runner block per rail. The B.RUNNER BLOCK CS KWD-030-FLS-C1-N-1 boasts an integrated all-around sealing system and offers high torque load capacity. For enhanced rigidity under various loading conditions, it includes two additional mounting screw holes at the center of the block. It also has an end-face fastening thread for various attachments. An optional feature includes an integrated, inductive, and wear-free measuring system that can be added to the runner block. Attachments can be mounted from both above and below the runner block, offering flexibility in design configurations. This product is pre-lubricated at the factory and ready for use on all SN/SNO ball guide rails while maintaining high load ratings in four main loading directions. It's engineered to meet demanding rigidity requirements while significantly reducing frictional oscillations and maintaining a low friction force level, especially under external loads. The B.RUNNER BLOCK CS KWD-030-FLS-C1-N-1 represents Bosch Rexroth's commitment to maximum precision in linear motion technology.
