BALL RUNNER BLOCK CARBON STEEL KWC-065-FLS-C0-N-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-FLS-C0-N-2 (R165369410) is a high-precision ball runner block designed for heavy-duty applications requiring maximum rigidity and load-bearing capacity. This runner block features a size 65 flange, long length, and standard height format FLS. The body of the runner block is made of unalloyed steel CS, ensuring durability and strength. It comes with a preload class C, indicating it is preload-free, and an accuracy class N for standard precision. This product does not include a ball chain and is preserved without initial lubrication. It also lacks attachment elements on both the left and right front reference edges but includes angular lube nipples that are loosely attached. The runner block body comes in the standard version with an overall length that allows compatibility with various guide rails. The B.RUNNER BLOCK CS KWC-065-FLS-C0-N-2 boasts features suitable for demanding rigidity requirements in heavy machine construction. It offers improved rigidity under liftoff and side loading conditions due to two additional mounting screw holes at the center of the block. The high torque load capacity and innovative channel design ensure minimum lubrication requirements while providing smooth, quiet operation due to an optimally designed ball return system. Additionally, this model has an optimized entry-zone geometry with a high number of balls to minimize elastic deflection variation. It offers different preload classes and end-face fastening threads for all attachments, ensuring versatility in its application. The ball runner block can be used on all SNS Ball Guide Rails with limitless interchangeability among all versions of Ball Guide Rail systems combined with Ball Runner Block versions. Its design accounts for compensation of misalignments without self-alignment capability while maintaining high static and dynamic load ratings as well as torsional moment load capacities across various sizes of profiled rail systems.
