BALL RUNNER BLOCK CARBON STEEL KWC-065-FLS-C1-H-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-FLS-C1-H-2 (R165361310) is a high-precision ball runner block designed for heavy-duty applications requiring maximum rigidity and load-bearing capacity. This component features a size 65 flange format FLS, which denotes its width, long length, and standard height. The runner block body is constructed from unalloyed steel CS and offers low preload (class C) and high accuracy (class H), ensuring reliable performance without a ball chain. This ball runner block is preserved but comes without initial lubrication or attachment elements on the left or right front reference edges. Angular lube nipples are loosely attached for ease of maintenance. The standard version of the runner block body has an overall length that allows for interchangeability with guide rails of every accuracy level. The product is engineered to provide enhanced rigidity under liftoff and side loading conditions due to two additional mounting screw holes at the center of the runner block. It also boasts a high torque load capacity, making it suitable for heavy machine construction. The innovative channel design ensures that only minimal lubrication quantities are required, contributing to smooth and quiet operation. The optimized entry-zone geometry and a high number of balls minimize variations in elastic deflection. This ball runner block can be utilized with all SNS Ball Guide Rails, offering limitless interchangeability with all versions of Ball Guide Rail systems. It supports different preload classes and features end-face fastening threads for attaching various components from above or below. Additional specifications include a dynamic load capacity C, static longitudinal moment load capacity ML, dynamic torsional moment load capacity Mt, and it operates within an ambient temperature range allowing short-term exposure to specified temperature extremes. The product also comes with standard seals to prevent contaminants from affecting its service life while maintaining low friction for efficient operation.
