R165361110

BALL RUNNER BLOCK CARBON STEEL KWC-065-FLS-C1-S-2

Manufacturer: Bosch Rexroth

Material #: R165361110

Model : B.RUNNER BLOCK CS KWC-065-FLS-C1-S-2


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-FLS-C1-S-2 (R165361110) is a high-precision ball runner block designed for demanding applications requiring superior rigidity and load-bearing capacity. This runner block is part of the Ball Rail Systems product group and is crafted from unalloyed steel CS, ensuring durability and robustness. It features a size 65 profile with a flanged, long, standard-height (FLS) format that provides a stable platform for heavy-duty machine construction. The B.RUNNER BLOCK CS boasts super precision (accuracy class SP) and has a low preload (preload class C), which makes it suitable for applications where smooth motion and accuracy are critical. It does not come with a ball chain or initial lubrication, allowing users to customize these elements based on their specific requirements. Additionally, this model includes angular lube nipples that are loosely attached for ease of maintenance. Designed with versatility in mind, the B.RUNNER BLOCK CS offers limitless interchangeability, meaning it can be combined with all SNS Ball Guide Rails regardless of accuracy. The innovative channel design ensures minimal lubrication requirements while providing smooth and quiet operation. The optimized ball return and guideway design, along with the high number of balls, reduce elastic deflection variations. This runner block can handle heavy loads in all directions due to its robust construction and additional mounting screw holes at the center. Its end-face fastening thread accommodates various attachments from both above and below the block. The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-FLS-C1-S-2 is an essential component for any system that demands high torque load capacity, improved rigidity under liftoff and side loading conditions, as well as reliable performance in extreme environments.

$1,307.99 USD

More are expected on January 20, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as January 20, 2025 when ordered in
