BALL RUNNER BLOCK CARBON STEEL KWD-045-FLS-C1-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-045-FLS-C1-H-1 (R165341320) is a high-precision ball runner block designed for linear motion applications requiring maximum precision and rigidity. This runner block features a size FLS format with a flange width, extended length, and standard height. It is constructed from unalloyed steel CS for durability and has been preloaded to class C for low preload and accuracy class H for high precision. The B.RUNNER BLOCK CS KWD-045-FLS-C1-H-1 is devoid of a ball chain, ensuring reduced frictional oscillations and a low friction force level, especially under external loads. Its exceptional dynamic characteristics are complemented by an innovative entry zone that can enhance travel accuracy by up to six times. Designed for demanding rigidity requirements, this runner block offers long-term lubrication potential spanning several years, facilitated by roller bearing grease Dynalub. This model boasts an integrated all-around sealing system and high torque load capacity, making it suitable for use with just one runner block per rail in certain applications. The inclusion of two additional mounting screw holes at the center enhances rigidity under lift-off and side loading conditions. The B.RUNNER BLOCK CS KWD-045-FLS-C1-H-1 also features optional integrated, inductive, and wear-free measuring systems. Attachments can be mounted from both above and below the runner block, which is compatible with all SN/SNO ball guide rails. It maintains high load ratings in all four main loading directions. The product comes factory prelubricated, ensuring immediate operational readiness upon installation. Furthermore, the Bosch Rexroth ball runner block has an overall length of . mm with interchangeable compatibility between the runner block and guide rails across every accuracy level. It's designed to meet the needs of various preload classes while maintaining high rigidity in all load directions. This model's robust design allows it to withstand challenging operating conditions while delivering consistent performance over time.
