BALL RUNNER BLOCK CARBON STEEL KWD-035-FLS-C1-U-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C1-U-1 (R16533192Z) is a high-precision ball runner block designed for linear motion applications requiring extreme accuracy and rigidity. The runner block features a size 35 flange, long body, and standard height configuration, made of unalloyed steel CS. It is distinguished by its ultra precision (UP) accuracy class and low preload (C), ensuring smooth motion with minimal friction. This model does not include a ball chain but comes with initial lubrication and preservation for immediate use. The B.RUNNER BLOCK CS is engineered to provide excellent dynamic characteristics, with the ability to handle demanding rigidity requirements while maintaining reduced frictional oscillations even under external loads. Its design allows for significantly improved travel accuracy, up to six times greater due to the patented entry zone. The block is equipped with long-term lubrication capabilities that can last several years and features metal-thread lube fittings on all sides for easy maintenance. Additionally, the runner block boasts high torque load capacity and various preload classes to suit different application needs. Its design ensures high rigidity in all load directions, making it possible to use just one runner block per rail in certain cases. The inclusion of two additional mounting screw holes at the center enhances rigidity under liftoff and side loading conditions. For maximum system rigidity, it employs a preloaded O-arrangement and offers an optional integrated, inductive, wear-free measuring system. Attachments can be mounted from both above and below the runner block, which is compatible with all SN/SNO ball guide rails and maintains high load ratings in all four main loading directions. The B.RUNNER BLOCK CS KWD-035-FLS-C1-U-1 comes prelubricated from the factory and features integrated all-around sealing for protection against contaminants. Its versatile design allows it to meet various application requirements while providing maximum precision and performance in linear motion systems.
