B.RUNNER BLOCK CS KWD-035-FLS-C1-N-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C1-N-2 (R165331424) is a high-precision ball runner block designed for linear motion applications. This model is part of Bosch Rexroth's Ball Rail Systems, which are known for their robustness and versatility in various industrial environments. The runner block features a four-row ball design, allowing point contact in all loading directions, which significantly reduces friction and heat generation during operation. This characteristic ensures a smooth and efficient motion with minimal resistance, making it suitable for applications requiring precise and low-friction linear movements. The R165331424 is constructed according to DIN standards, ensuring compatibility and interchangeability with other components in the system. It comes equipped with universal standard seals (SS) that provide effective protection against contaminants such as dirt, chips, and coolants, thus extending the service life of the runner block. Additionally, options like low friction seal (LS), double-lip seal (DS), front seal, FKM seal, and cover plate wiper are available to cater to special environmental requirements or increased exposure to harsh media. This ball runner block also boasts long-term lubrication capabilities that can last several years without maintenance. It includes lube fittings with metal threads on all sides for easy access when lubrication is eventually required. The design incorporates an end-face fastening thread for various attachments and an integrated all-around sealing system for added protection against contamination. High torque capacity and different preload classes are available to accommodate diverse application needs. The B.RUNNER BLOCK CS KWD-035-FLS-C1-N-2 offers exceptional rigidity in all load directions due to its construction, which can support applications using just one runner block per rail if needed. Enhanced system rigidity is achieved through pretensioned O-arrangement of balls within the block. For added functionality, an optional integrated inductive measuring system can be included for precise positioning tasks. Attachments on the Ball Runner Block can be mounted from both above and below for flexibility in assembly configurations. Furthermore, this model is compatible with all SN/SNO Ball Guide Rails by Bosch Rexroth and maintains high load ratings in all four main loading directions right out of the factory pre-lubricated state.
