BALL RUNNER BLOCK CARBON STEEL KWD-035-FLS-C1-S-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C1-S-1 (R165331122) is a high-precision ball runner block designed for linear motion applications requiring super precision and low preload. This model features a size E profiled rail system, with the runner block body made of unalloyed steel CS. It boasts an accuracy class SP for super precision and a preload class C indicating low preload, ensuring smooth motion and reduced frictional oscillations, especially under external loads. The B.RUNNER BLOCK CS KWD-035-FLS-C1-S-1 is equipped with a ball chain for quiet operation and optimal travel behavior. Its design includes initial lubrication and preservation, ensuring long-term maintenance-free operation. The roller bearing grease used is Dynalub 510, which contributes to the long service life of the runner block. This runner block offers exceptional dynamic characteristics due to its design that permits high rigidity in all load directions, making it suitable for applications that require only one runner block per rail. The inclusion of two additional mounting screw holes at the center enhances rigidity under liftoff and side-loading conditions. Furthermore, it features an integrated all-around sealing system and has high torque load capacity. The product allows for attachments to be mounted from both above and below the runner block, providing flexibility in various installation scenarios. This model can be utilized on all SN/SNO ball guide rails by Bosch Rexroth and supports high load ratings in all four main directions of loading. It comes without attachment elements on both left and right front reference edges but includes straight lube connections loosely attached. Overall, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FLS-C1-S-1 (R165331122) is designed for demanding applications where maximum precision and rigidity are essential. It offers excellent dynamic properties while maintaining low noise levels and providing options for long-term lubrication over several years.
