BALL RUNNER BLOCK CARBON STEEL KWD-025-FLS-C0-N-1
Manufacturer: Bosch Rexroth
Material #: R165329422
Model : B.RUNNER BLOCK CS KWD-025-FLS-C0-N-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-FLS-C0-N-1 (R165329422) is a ball runner block designed for high precision and rigidity in linear motion applications. This runner block features a size 25 profile, with an FLS format which indicates a flanged, long, and standard height block. The body of the runner block is constructed from unalloyed steel CS, ensuring durability and consistent performance.
This product comes with a preload class C, meaning it is preload-free for ease of movement without compromising on precision. It falls under accuracy class N, signifying standard accuracy levels suitable for various applications. A distinctive feature of this model is the inclusion of a ball chain, which contributes to low noise operation and optimal travel behavior.
The B.RUNNER BLOCK CS KWD-025-FLS-C0-N-1 boasts an initial lubrication and preservation treatment to reduce maintenance needs over time. It has been designed with roller bearing grease Dynalub 510 for reliable operation. The runner block does not include attachment elements at either front reference edge but does offer straight lube connection that's loosely attached.
One of the key advantages of this ball runner block is its interchangeability; it can be combined with guide rails of every accuracy level to suit diverse requirements. The product excels in applications demanding stringent rigidity criteria, as it can significantly reduce friction oscillations while maintaining a low friction force level even when externally loaded.
Additional design benefits include long-term lubrication capabilities spanning several years, metal threaded lube fittings on all sides, end-face fastening threads for various attachments, and integrated all-around sealing for protection against contaminants. The high torque load capacity and different preload classes available make it versatile across multiple uses.
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-FLS-C0-N-1 ensures maximum system rigidity thanks to its preloaded O-arrangement and offers enhanced rigidity under liftoff and side loading conditions due to additional mounting screw holes at the center of the block. Furthermore, it can accommodate an optional integrated inductive measuring system for precise tracking of movement without wear concerns. Compatible with all SN/SNO ball guide rails and designed to handle high load ratings in all four main directions of loading, this ball runner block is prelubricated at the factory for immediate use upon installation.
$262.38 USD
Availability: 3 In Stock
Available for immediate shipmentQty: Delivered as early as November 6, 2024 when ordered in
