BALL RUNNER BLOCK CARBON STEEL KWD-015-FLS-C0-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-FLS-C0-N-1 (R165319420) is a high-precision ball runner block designed for linear motion applications requiring exacting rigidity and dynamic characteristics. This model features a flange width, long length, and standard height, with the body constructed from unalloyed steel CS. It falls under preload class C, indicating it is preload-free, and accuracy class N for standard precision. This runner block does not include a ball chain but comes with initial lubrication and preservation using Roller bearing grease Dynalub. It is designed without attachment elements on either the left or right front reference edge and includes a straight lube connection that is loosely attached. The overall length of the runner block is specified in the product details. One of its key attributes is interchangeability; it can be combined with guide rails of every accuracy level to meet various application needs. The product boasts excellent dynamic properties, including reduced frictional oscillations and low friction force levels, especially under external load conditions. It offers maximum precision thanks to a patented entry zone that enhances travel accuracy by up to six times. Long-term lubrication capabilities extend over several years due to lube fittings with metal threads on all sides. The runner block also features integrated all-around sealing and high torque load capacity across different preload classes. Its design allows for use with just one runner block per rail due to its high rigidity in all load directions. Additionally, two extra mounting screw holes at the center enhance rigidity under liftoff and side loading conditions. Optional features include an integrated, inductive, wear-free measuring system for precise movement tracking. Attachments can be mounted from both above and below the runner block, providing flexibility in assembly. Compatible with all SN/SNO ball guide rails, this model maintains high load ratings in all four main loading directions and comes prelubricated from the factory for immediate use upon installation.
