BALL RUNNER BLOCK CARBON STEEL KWC-065-FNS-C1-S-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWC-065-FNS-C1-S-2 (R165161110) is a ball runner block designed for high rigidity and heavy-duty applications. This linear guide component is part of the Ball Rail Systems product group and is well-suited for use in heavy machine construction due to its extremely high load-bearing capacity. The ball runner block features a size CS steel body with an FNS format, indicating a flange width, normal length, and standard height. Its low preload class C ensures smooth motion with minimal resistance, while the super precision accuracy class SP provides exceptional guiding accuracy. Engineered without a ball chain and initially unlubricated, this model prioritizes preservation and maintenance simplicity. The angular lube nipples are loosely attached, facilitating easy lubrication when necessary. The overall length of the runner block allows for compatibility across various guide rail sizes, ensuring interchangeability and flexibility in application. The B.RUNNER BLOCK CS boasts improved rigidity under liftoff and side-loading conditions due to additional mounting screw holes at the center of the block. It also features high torque load capacity and allows attachments to be mounted from both above and below. Innovative channel design within the runner block reduces the need for large quantities of lubrication while ensuring smooth operation. Its optimized ball return system and guideway design contribute to quiet running characteristics, while an optimized entry-zone geometry coupled with a high number of balls reduces elastic deflection variation. The runner block can be used on all SNS Ball Guide Rails, offering limitless interchangeability options as all Ball Guide Rail versions can be combined with all Ball Runner Block versions without restriction. This Bosch Rexroth linear guide component is designed to withstand ambient temperatures ranging from minimum to maximum degrees Celsius (as per specific product guidelines) and offers dynamic load capacities calculated based on DIN ISO standards for travel distances. With its robust construction and versatile design, this ball runner block is engineered for performance in demanding industrial environments where precision linear movement is crucial.
