BALL RUNNER BLOCK CARBON STEEL KWD-035-FNS-C1-U-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-FNS-C1-U-1 (R16513192Z) is a state-of-the-art ball runner block designed for ultra-precise linear motion applications. This model features a size FNS format, which includes a width flange, normal length, and standard height. The runner block body is constructed from unalloyed steel CS, ensuring durability and robustness for demanding environments. This particular ball runner block is distinguished by its low preload (preload class C) and ultra precision accuracy class UP, making it ideal for applications that require maximum precision. Despite not having a ball chain, the unit is prelubricated with Roller bearing grease Dynalub to ensure smooth operation from the start. One of the key capabilities of this model is its high rigidity, which makes it suitable for applications with stringent rigidity requirements. It boasts excellent dynamic characteristics, including reduced frictional oscillations and low friction force levels even under external loads. The patented entry zone of the runner block significantly enhances travel accuracy by up to six times compared to standard models. The B.RUNNER BLOCK CS KWD-035-FNS-C1-U-1 also features an all-around sealing system for protection against contaminants and allows for attachments to be mounted from both above and below. The lube fittings come with metal threads on all sides for easy maintenance, while the endface fastening thread accommodates all types of attachments. In terms of design, the runner block body is in its standard version with an overall length specified in the product details. It offers interchangeability with guide rails across various accuracies. Moreover, its design supports high torque load capacity and offers different preload classes to match specific application needs. The Bosch Rexroth ball runner block can be used on all SNS/SNO ball guide rails and is capable of long-term lubrication over several years without requiring frequent maintenance. Its design allows it to sustain high load ratings in all four main loading directions. The product's specifications also note that it can accommodate optional integrated measuring systems if needed. In summary, this Bosch Rexroth ball runner block represents an advanced solution for linear motion systems requiring high precision, rigidity, and dynamic performance across a range of industrial applications.
