R162471321

BALL RUNNER BLOCK CARBON STEEL KWD-030-SLH-C1-H-1

Manufacturer: Bosch Rexroth

Material #: R162471321

Model : B.RUNNER BLOCK CS KWD-030-SLH-C1-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SLH-C1-H-1 (R162471321) is a high-precision ball runner block designed for linear motion applications requiring compactness, rigidity, and accuracy. This runner block features a slimline width, long length, and high height format (SLH), constructed from unalloyed steel CS for durability. It is classified under preload class C, indicating a low preload to reduce friction without compromising performance, and accuracy class H for highly accurate movement. The B.RUNNER BLOCK CS KWD-030-SLH-C1-H-1 is devoid of a ball chain, instead utilizing an advanced ball return system to ensure smooth and quiet operation. It comes with initial lubrication and preservation for long-term maintenance-free operation. The runner block body is in the standard version with an overall length specific to the product design. This runner block boasts excellent dynamic characteristics with different preload classes available. It can be used on all SNSSNO ball guide rails due to its universal compatibility within each accuracy class. The product offers high rigidity in all load directions which enables the use of just one runner block per rail in certain applications. Additionally, it has a high torque load capacity. Designed with interchangeability in mind, this runner block can be combined with various guide rails to meet specific application requirements. Its patented entry zone significantly improves travel accuracy by up to six times compared to conventional designs. The B.RUNNER BLOCK CS KWD-030-SLH-C1-H-1 is suitable for environments where space is limited in the transverse direction but where high rigidity and precision are essential. Its design allows for self-alignment to compensate for misalignments during installation or operation. The product also features endface fastening threads that are compatible with all attachments, enhancing its versatility across numerous applications.

$278.61 USD

More are expected on February 25, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as February 25, 2025 when ordered in
