BALL RUNNER BLOCK CARBON STEEL KWD-020-SLS-C2-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-020-SLS-C2-X-1 (R162382820) is a state-of-the-art ball runner block designed for high precision linear movement and load-bearing applications. This component is part of the Ball Rail Systems, which are known for their robustness and versatility. The runner block body is constructed from unalloyed steel CS, ensuring durability and strength. This particular model features an SLS size format, indicating a slimline width, long length, and standard height. It boasts an extra precision accuracy class (XP) and a medium preload class C, without the inclusion of a ball chain. The runner block comes pre-lubricated with roller bearing grease Dynalub for initial use and has preservation measures in place. The dynamic load capacity C of this runner block is determined according to DIN ISO standards based on a 100 km travel distance. It is designed to handle very high loads with equal load ratings in all four main loading directions. The optimized entry-zone geometry combined with a high number of balls reduces variation in elastic deflection. Furthermore, the B.RUNNER BLOCK CS KWD-020-SLS-C2-X-1 can be interchangeably combined with any guide rails within its accuracy class thanks to its limitless interchangeability feature. Attachments can be mounted from above due to its end-face fastening thread design. It also includes an integrated all-around sealing system and a minimum quantity lubrication system with an oil reservoir. Suitable for environments where space is restricted in the transverse direction, this ball runner block can endure ambient temperatures ranging from minimum to maximum degrees Celsius for short periods. For continuous operation at negative temperatures or specific environmental conditions, consultation with Bosch Rexroth is advised. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-020-SLS-C2-X-1 (R162382820) provides excellent dynamic characteristics suitable for various applications requiring precise linear motion control and significant load capacity.
