BALL RUNNER BLOCK CARBON STEEL KWD-025-SLS-C2-H-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SLS-C2-H-1 (R162322320) is a high-precision ball runner block designed for linear guidance systems. This runner block features a slimline width, extended length, and standard height, making it suitable for applications with limited space in the transverse direction. It is constructed from unalloyed steel CS and offers medium preload (class C) and high accuracy (class H), ensuring reliable performance under various loading conditions. The B.RUNNER BLOCK CS KWD-025-SLS-C2-H-1 is devoid of a ball chain but comes with initial lubrication and preservation, using the Roller bearing grease Dynalub. This model allows for straightforward attachment from above without the need for an attachment element on either front reference edge. The lube connection is straight and loosely attached, providing flexibility during maintenance. With an overall length of . mm, this runner block is interchangeable within each accuracy class, offering limitless combinations with guide rails to meet specific application requirements. It boasts high load ratings in all four main directions of loading and supports long-term lubrication over several years. The optimized entry-zone geometry coupled with a high number of balls reduces elastic deflection variation. This model also incorporates an all-around sealing system to protect against contaminants and features a minimum quantity lubrication system with an integrated oil reservoir. The end-face fastening thread accommodates various attachments for versatile use across different environments. Suitable for all SN/SNO ball guide rails, the B.RUNNER BLOCK CS KWD-025-SLS-C2-H-1 demonstrates excellent dynamic characteristics and torque load capacity. Its self-aligning capability aids in compensating for misalignments while maintaining low friction coefficients between . and ., enhancing overall system efficiency. In summary, this Bosch Rexroth ball runner block is engineered to provide exceptional guidance performance with its robust design, precision engineering, and versatile features tailored to demanding linear motion applications.
