BALL RUNNER BLOCK CARBON STEEL KWD-025-SLS-C2-P-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-025-SLS-C2-P-1 (R162322222) is a precision ball runner block designed for linear motion applications requiring high accuracy and medium preload. This runner block features a slimline width, long length, and standard height (SLS format), constructed from unalloyed steel CS. It offers a precision accuracy class P and comes with an integrated ball chain to ensure smooth travel behavior and reduced noise levels. The B.RUNNER BLOCK CS is notable for its high load ratings in all four main loading directions, making it suitable for applications with restricted space in the transverse direction and those that experience very high loads. The optimized entry-zone geometry, combined with a high number of balls, minimizes the variation in elastic deflection. This model also boasts an excellent dynamic characteristic which is crucial for applications requiring precise movements at various speeds. Designed to be user-friendly, attachments can be mounted from above the runner block body, which comes in a standard version without attachment elements on either front reference edge. The straight lube connection is loosely attached for ease of maintenance. Additionally, it features integrated all-around sealing to protect against contaminants and a minimum quantity lubrication system with an integrated reservoir for oil lubrication. This ball runner block is compatible with all SN/SNO ball guide rails within each accuracy class due to its limitless interchangeability feature. The overall length of the runner block is specified as . mm, and it has been designed to accommodate high torque loads efficiently. For specific environmental conditions and operational capabilities such as permissible ambient temperature ranges, dynamic load capacity C, static load rating C0, dynamic torsional moment load capacity Mt, friction coefficient values, maximum permissible linear speed vmax, preload force F0 values among others are detailed within the product's specifications. This ensures users can select the appropriate runner block according to their application requirements while adhering to DIN ISO standards for travel distance considerations when determining dynamic capacities and load moments.
