BALL RUNNER BLOCK CARBON STEEL KWD-015-SLS-C1-N-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SLS-C1-N-1 (R162311422) is a high-precision ball runner block designed for linear motion applications requiring compact size, high load capacity, and low noise operation. This runner block features a slimline width, long length, and standard height (SLS format), crafted from unalloyed steel CS for durability. It is engineered with a low preload class C and normal accuracy class N, ensuring smooth movement and standard precision. The B.RUNNER BLOCK CS KWD-015-SLS-C1-N-1 comes equipped with a ball chain that enhances travel behavior while reducing noise levels. It also boasts an initial lubrication and preservation for reduced maintenance needs. The roller bearing grease Dynalub extends the life of the runner block by providing long-term lubrication over several years. Designed for versatility, this runner block can be combined with various guide rails within the same accuracy class due to its limitless interchangeability feature. It accommodates very high loads in all four main loading directions and is capable of handling high torque loads due to its optimized entry-zone geometry and numerous balls which minimize elastic deflection variations. For ease of attachment, mounting elements can be affixed from above the runner block, which also includes an all-around seal for protection against contaminants. An integrated minimum quantity lubrication system allows for oil lubrication without frequent replenishment. This Bosch Rexroth runner block is compatible with all SN/SNO ball guide rails and showcases exceptional dynamic characteristics suitable for applications with restricted space in the transverse direction or where very high loads are anticipated. Additionally, it supports ambient operating temperatures ranging from minimum permissible values to maximum permissible values (specific temperature ranges not provided). The dynamic load capacity C and other load capacities are determined in accordance with DIN ISO standards to ensure reliable performance under demanding conditions.
