R16227132Z

BALL RUNNER BLOCK CARBON STEEL KWD-030-SNS-C1-H-1

Manufacturer: Bosch Rexroth

Material #: R16227132Z

Model : B.RUNNER BLOCK CS KWD-030-SNS-C1-H-1


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-030-SNS-C1-H-1 (R16227132Z) is a high precision ball runner block designed for linear motion applications requiring compactness and high load-bearing capacity. This model is part of the Ball Rail Systems line, specifically crafted for restricted space in the transverse direction and can handle high torque loads effectively. The runner block boasts an overall length of . mm and a body made from unalloyed steel CS, ensuring durability and robust performance. The B.RUNNER BLOCK CS is notable for its low preload (Preload class C) and high accuracy (Accuracy class H), making it suitable for applications demanding precise movement control. It comes without a ball chain but includes initial lubrication and preservation to ensure smooth operation right out of the box. The product uses roller bearing grease Dynalub, which contributes to its long-term lubrication capabilities, potentially extending over several years. Designed with optimized entry-zone geometry, this runner block minimizes variation in elastic deflection while allowing attachments to be mounted from above. Its integrated all-around sealing provides protection against contaminants, thereby prolonging its service life. Additionally, it features a minimum quantity lubrication system with an integrated reservoir for oil lubrication. This model's dynamic characteristics are enhanced by the ability to be used on all SNS/SNO ball guide rails, offering excellent dynamic performance. It also supports various preload classes and boasts interchangeability within each accuracy class, allowing flexibility in combining with different guide rails. The B.RUNNER BLOCK CS has an end-face fastening thread compatible with all attachments and can withstand ambient temperatures ranging from min ... max °C short term. Its static load rating C0 and dynamic load capacity C are determined based on DIN ISO standards. The product's design ensures self-alignment to compensate for misalignments without using a ball chain standard.

$241.70 USD

More are expected on March 21, 2025
  Add to Cart

Status: This product is temporarily out of stock.


Qty: Delivered as early as March 21, 2025 when ordered in
