BALL RUNNER BLOCK CARBON STEEL KWD-045-SNS-C2-P-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-045-SNS-C2-P-1 (R162242220) is a high-precision ball runner block designed for linear motion applications where space is limited and high load capacity is required. This runner block, part of the Ball Rail Systems product group, is characterized by its slimline width, normal length, and standard height format (SNS). It features a steel CS runner block body with medium preload class C and precision accuracy class P, ensuring reliable and accurate movement. The B.RUNNER BLOCK CS KWD-045-SNS-C2-P-1 does not come with a ball chain but includes initial lubrication and preservation to maintain performance over extended periods. The roller bearing grease Dynalub enhances its durability. This model has an overall length of . mm and supports high torque load capacities in all four main loading directions. Its optimized entry-zone geometry with a high number of balls reduces variation in elastic deflection. This ball runner block can be used on all SNS/SNO ball guide rails, offering excellent dynamic characteristics for various applications. Its design allows for attachments to be mounted from above and includes integrated all-around sealing to protect against contaminants. The unit also features an end-face fastening thread for attachments and an integrated minimum quantity lubrication system. The B.RUNNER BLOCK CS KWD-045-SNS-C2-P-1 operates within a permissible ambient temperature range of min ... max °C (admissible for short periods), with the capability to function at negative temperatures after consultation. It boasts impressive dynamic load capacity C, static load rating C0, dynamic torsional moment load capacity Mt, static longitudinal moment load capacity ML, and can accommodate maximum accelerations amax. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-045-SNS-C2-P-1 (R162242220) offers versatility for limited space applications requiring precise linear motion control with robust load handling capabilities while ensuring interchangeability within each accuracy class for customized solutions.
