BALL RUNNER BLOCK CARBON STEEL KWD-035-SNS-C1-X-1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SNS-C1-X-1 (R16223182Z) is an advanced ball runner block designed for linear motion applications requiring high precision and low friction. This runner block is part of the Ball Rail Systems product line, which emphasizes accuracy and durability. The model features a slimline width, standard height, and normal length (SNS format), crafted from unalloyed steel CS for robustness. It comes with a low preload class C and boasts an extra precision accuracy class XP. This runner block has been engineered without a ball chain yet includes initial lubrication and preservation, ensuring smooth operation from the outset. It utilizes roller bearing grease Dynalub, enhancing its longevity and performance. The design allows for straightforward attachment from above without the need for left or right front reference edges on the attachment elements. A straight lube connection is included but comes loosely attached. The B.RUNNER BLOCK CS KWD-035-SNS-C1-X-1 is designed to function in restricted spaces while handling high torque loads efficiently across all four main loading directions. Its optimized entry-zone geometry coupled with a high number of balls reduces elastic deflection variance, ensuring consistent performance. The unit is also equipped with integrated all-around sealing to protect against contaminants and features a minimum quantity lubrication system that can sustain long-term lubrication over several years. Compatibility with all SN/SNO ball guide rails allows for limitless interchangeability within each accuracy class, offering flexibility in system design. Additionally, it has excellent dynamic characteristics due to its prelubrication at the factory and can operate within an ambient temperature range of -10°C to +100°C (short-term permissible temperatures may vary). The dynamic load capacity C and static longitudinal moment load capacity ML are calculated based on DIN ISO standards for 100 km travel distance. In summary, the Bosch Rexroth B.RUNNER BLOCK CS KWD-035-SNS-C1-X-1 (R16223182Z) offers superior precision, flexibility, and durability for various linear motion applications where space constraints exist or high torque loads are expected.
