BALL RUNNER BLOCK CARBON STEEL KWD-015-SNH-C0-H-1
Manufacturer: Bosch Rexroth
Material #: R162119320
Model : B.RUNNER BLOCK CS KWD-015-SNH-C0-H-1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SNH-C0-H-1 (R162119320) is a high-precision ball runner block designed for linear motion applications where space is limited in the transverse direction and high rigidity is required. This runner block features a slimline width, standard length, and high height format (SNH), constructed from unalloyed steel CS, ensuring durability and performance. It belongs to preload class C, indicating that it is preload-free, and accuracy class H for high accuracy requirements.
The B.RUNNER BLOCK CS KWD-015-SNH-C0-H-1 does not include a ball chain but comes with initial lubrication and preservation, utilizing roller bearing grease Dynalub for reduced maintenance. It supports endface fastening with threads for various attachments and offers smooth operation due to its optimized ball return system. The runner block's design ensures low frictional oscillations and a low friction force level even under external loads.
This model boasts a patented entry zone that significantly enhances travel accuracy by up to six times compared to standard systems. Its rigidity allows for use with only one runner block per rail if needed, while the high torque load capacity extends its application range. Interchangeability is a key feature of this product; it can be combined with all ball guide rail systems within each accuracy class.
In terms of lubrication, long-term options are available over several years, reducing the need for frequent maintenance. The B.RUNNER BLOCK CS KWD-015-SNH-C0-H-1 operates quietly and smoothly due to its sophisticated design and can accommodate different preload classes based on application needs.
Overall, the Bosch Rexroth B.RUNNER BLOCK CS KWD-015-SNH-C0-H-1 offers exceptional dynamic characteristics suitable for various industrial applications where precision linear movement is critical.
$163.56 USD
More are expected on March 28, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 28, 2025 when ordered in
