BRAKING ELEMENT MBPS 2005 AS1A &
Manufacturer: Bosch Rexroth
Material #: R161984031
Model : BRAKING ELEMENT MBPS 2005 AS1A &
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BRAKING ELEMENT MBPS 2005 AS1A (R161984031) is a high-performance pneumatic braking unit designed for dynamic and static stabilization in axial directions. This braking element is specifically engineered to clamp and brake without pressurization, utilizing spring energy for its operation. It boasts up to 1 million clamping cycles and can handle up to 50,000 emergency braking operations, ensuring reliability and longevity in demanding applications.
The unit features integrated all-around sealing and is maintenance-free, with a Bd value indicating its high continuous output capacity. Its mechanical gate valve gear mechanism contributes to its robustness, while the solid, rigid steel housing with chemical nickel plating ensures durability. The low air consumption of the BRAKING ELEMENT MBPS 2005 AS1A makes it an efficient solution for various pneumatic applications.
Capable of delivering holding forces up to 25,000 N at just 4.5 bar release pressure thanks to addons with three pistons connected in series combined with strong springs, this model provides high positioning accuracy for precise operations. The permissible ambient temperature range for this unit spans from -30°C to +80°C, accommodating a wide array of working environments.
Designed to be compatible with all SNS ball guide rails, this model can be utilized across size B profiled rail systems through size H profiled rail systems. Its compact design includes a height of the runner block at 28 mm and accommodates various sizes of profiled rail systems including A, D, E, N, and S thread diameter profiled rail systems M12. The nominal size functionality ensures adaptability across different system requirements.
In summary, the Bosch Rexroth BRAKING ELEMENT MBPS 2005 AS1A (R161984031) stands out as a versatile and robust component suitable for a multitude of clamping and braking applications where high performance and reliability are essential.
$2,272.23 USD
More are expected on March 10, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as March 10, 2025 when ordered in
