BRAKING ELEMENT KBH 6505 AS2A

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BRAKING ELEMENT KBH 6505 AS2A (R161964020) is a robust hydraulic braking unit designed for use with ball rail systems. It is compatible with the SNS series of ball guide rails and can be utilized across various sizes, including Size A, B, E, H, and N profiled rail systems. This unit boasts a solid, rigid steel housing that is chemically nickel-plated for durability and resistance against harsh conditions. With the capability to withstand up to 1 million clamping cycles and up to 250,000 emergency braking operations, this braking element ensures long-term reliability in demanding applications. The KBH 6505 AS2A operates with a hydraulic pressure of up to 120 bar for clamping and uses a special pressure diaphragm technology that guarantees maximum functional reliability without pressure losses or leakage. This technology also contributes to the high positioning accuracy of the unit. For ease of installation and maintenance, it features threaded connections on both sides for the hydraulic connection. The integrated all-around sealing protects against contaminants and ensures consistent performance. Additionally, its compact design includes integrated positive-locking contact profiles that provide maximum axial rigidity when engaged. The release pressure for this model is set at 60 bar, allowing for quick disengagement when necessary. The KBH 6505 AS2A has been designed to allow minimal displacement during operation and can operate within an ambient temperature range of -10°C to +80°C. This heavy-duty model is equipped with a pretensioned return spring which enables short decompression cycles after braking. It's suitable for various applications where precise control over movement is required along with reliable stopping power in safety-critical situations. The nominal size and weight specifications ensure compatibility with corresponding guide rail systems while maintaining ease of integration into existing setups.
