CLAMPING ELEMENT KWH 2505 AS3A ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CLAMPING ELEMENT KWH 2505 AS3A (R161924231) is a robust hydraulic clamping unit designed for high precision and reliability in securing ball rail systems. This clamping element can be utilized with all SNS ball guide rails, ensuring versatility across various sizes, including Size B, Size H, Size E, Size A, Size N, and Size S profiled rail systems. It is engineered for optimal performance with a solid steel housing that is chemically nickel-plated to resist corrosion and wear. The unit's functional principle relies on hydraulic pressure ranging from 50 to 450 bar to clamp with pressure, while decompression is achieved through spring force. This allows for quick release cycles when necessary. The clamping element boasts high positioning accuracy and offers continuously adjustable pressure without the risk of pressure losses or leakage thanks to its special pressure diaphragm technology. With integrated all-around sealing and positivelocking contact profiles, this clamping element provides maximum axial rigidity and functional reliability over an impressive service life of up to 1 million clamping cycles (Bd value). The design also features threaded connections on both sides for the hydraulic link and accommodates a wide range of ambient temperatures from -20°C up to +80°C. Its compact size does not compromise its holding force capabilities; it maintains a strong hold on the rail with the help of its large-surface contact profiles. The KWH 2505 AS3A model comes in a nominal size suitable for different applications requiring precise motion control and secure positioning. It's an ideal choice for those seeking a durable and precise clamping solution within linear guide systems.
