BALL GUIDE RAIL CARBON STEEL KSA-020-SNS-S-MB-00

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160780131) is a high-precision ball guide rail designed for robust and accurate linear motion applications. This guide rail is part of the SNS series, which features a slimline width, normal length, and standard height for efficient space utilization. Constructed from carbon steel (CS), it offers exceptional durability and rigidity, ensuring maximum performance even under high load conditions. The B.GUIDE RAIL CS has an accuracy class of super precision, indicating its capability to provide extremely precise movements suitable for demanding applications. It comes as a one-piece section, eliminating the need for additional assembly and ensuring ease of installation. The fastener MB allows for bolting from below, facilitating a secure and stable mounting process. This model does not include a cover strip but boasts the best sealing action with its end seals, allowing it to handle greater side loads effectively. Its design permits maximum rigidity in all load directions and is capable of supporting high torque loads without requiring extra space at the rail ends. The guide rail's profiled T-systems are made from carbon steel and are designed to withstand permissible ambient temperatures within specified ranges, making it versatile for various operating environments. The recommended rail length formula takes into account the number of holes (nB) and pitch (T) to ensure optimal performance. In summary, the Bosch Rexroth B.GUIDE RAIL CS (R160780131) is an exceptionally precise and sturdy ball guide rail system ideal for applications requiring reliable linear motion with minimal maintenance. Its construction allows for mounting from below while providing superior sealing and load-bearing capabilities.
