BALL GUIDE RAIL CARBON STEEL KSA-025-SNS-H-MB-00
Manufacturer: Bosch Rexroth
Material #: R160720331
Model : B.GUIDE RAIL CS KSA-025-SNS-H-MB-00
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160720331) is a high-precision ball guide rail system designed for applications requiring maximum rigidity and torque load capacity. This one-piece guide rail is made of carbon steel (CS) and features a slimline width, standard height, and normal length, conforming to the SNS size format. The B.GUIDE RAIL CS is engineered for bolting from below with the fastener MB type, ensuring a secure and stable installation.
This model boasts a high accuracy class, making it suitable for tasks that demand exact movement control. The absence of a cover strip signifies that the rail is optimized for environments where additional protection is not necessary. The robust design allows for greater side loads and ensures the best sealing action with end seals to maintain performance over time.
The guide rail's T profiled system enhances its compatibility with various applications while maintaining a minimal footprint at the ends of the rail, thus not requiring extra space for installation. It can withstand permissible ambient temperatures ranging from minimum to maximum degrees Celsius, even tolerating short-term exposure beyond this range (for operation at negative temperatures or specific conditions, consultation with Bosch Rexroth is advised).
With its one-piece construction providing seamless movement and no interruptions in travel length, which can reach up to Lmax meters, this product is ideal for scenarios where uninterrupted linear motion is critical. The weight per meter and nominal size specifications ensure that users can select the appropriate size and mass for their specific needs.
Overall, the Bosch Rexroth B.GUIDE RAIL CS (R160720331) represents an optimal solution for those seeking a durable, accurate ball rail system without unnecessary complexity or additional space requirements at installation points.
This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
