R160720131

BALL GUIDE RAIL CARBON STEEL KSA-025-SNS-S-MB-00

Manufacturer: Bosch Rexroth

Material #: R160720131

Model : B.GUIDE RAIL CS KSA-025-SNS-S-MB-00


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160720131) is a high-precision ball guide rail designed for applications that require maximum rigidity and high torque load capacity. This model belongs to the SNS size format, which features a slimline width, standard height, and normal length, making it an optimal choice for space-conscious designs. Constructed from carbon steel CS, the guide rail ensures durability and reliable performance. The B.GUIDE RAIL CS is characterized by its super precision accuracy class, which guarantees exceptional guidance accuracy and smooth motion. It comes as a one-piece section, offering ease of installation and maintenance. The rail is designed for bolting from below (fastener MB), providing a secure and robust mounting option that contributes to the system's overall rigidity. Notably, this model does not include a cover strip; however, it still delivers excellent sealing action at the end seals. It is capable of withstanding greater side loads compared to other models in its category. The absence of extra space required at the rail ends allows for more efficient use of available space within machine designs. The linear guide conforms to DIN standards for linear guides selection and boasts a permissible ambient temperature range suitable for various operating environments. Its pitch T guide rail specification ensures compatibility with corresponding runner blocks or carriages designed for ball rail systems. With its nominal size specifications and weight details provided in kg/m, the Bosch Rexroth B.GUIDE RAIL CS offers precise information for engineers to calculate the recommended rail length formula effectively. The product's design facilitates easy handling and integration into linear motion systems where high precision and compactness are vital requirements.

This product is not available. CLICK HERE to create a support ticket for us to locate your part or a suitable replacement
