BALL GUIDE RAIL CARBON STEEL KSA-045-SNS-H-MA-BS

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160543362) is a state-of-the-art ball guide rail system designed to deliver exceptional precision and rigidity in various applications. This guide rail is part of the SNS series, which stands out for its slimline width, standard height, and normal length, ensuring a compact yet robust design suitable for harsh environments. The rail itself is crafted from high-quality carbon steel CS, ensuring durability and resistance to wear. This model features a high accuracy class with a two-piece section construction that allows for maximum rigidity in all load directions and high torque load capacity. It is equipped with a fastener MA for bolting from above, simplifying the installation process. The inclusion of a cover strip made from corrosion-resistant spring steel, compliant with DIN EN standards, along with aluminum strip clamps that lack threaded holes on end faces, provide additional protection and ease of maintenance. The B.GUIDE RAIL CS is designed without the need for an end-face hole for the strip clamp installation, which streamlines the mounting process. It can withstand permissible ambient temperatures ranging from -20°C to 80°C (with higher temperatures allowed for short periods), making it versatile for use in varying climatic conditions. With a weight of 2.7 kg/m and an optimal length formula based on the number of holes and pitch (L = nB * T), this profiled rail system offers flexibility in design to meet specific application requirements. Its size T profiled rail systems are complemented by the recommended size N tolerance profiled rail systems. Overall, Bosch Rexroth's B.GUIDE RAIL CS provides reliable linear motion guidance with its robust construction and thoughtful design elements like the universal cover strip that saves time during installation while ensuring long-lasting performance.
