BALL GUIDE RAIL CARBON STEEL KSA-015-SNS-U-MA-AB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth B.GUIDE RAIL CS (R160516931) is a high-precision ball guide rail designed to provide maximum rigidity and torque load capacity in various applications. This guide rail is part of the slimline SNS series, known for its compact design, with a standard length and height format. It is constructed from carbon steel CS, ensuring durability and long-lasting performance even in harsh environments. The B.GUIDE RAIL CS features an ultra precision accuracy class, making it suitable for applications that require the highest levels of precision. It comes as a one-piece rail configuration which simplifies installation and maintains structural integrity. The fastening method MA indicates that this guide rail is designed for bolting from above, offering ease of assembly. To protect against corrosion and environmental factors, this model includes a cover strip made from corrosion-resistant spring steel compliant with DIN EN standards. Additionally, it has plastic protective caps with threaded holes on the end faces to safeguard the mounting hardware and internal mechanisms. This product offers excellent performance with its ability to handle high torque loads efficiently across all directions. The cover strip serves as a single solution for all holes when mounting from above, further enhancing the convenience of installation. Its profiled T-rail system allows for flexibility in mounting and application. With a weight specification of 2.9 kg/m and recommended pitch T for hole spacing at 60 mm (for size N profiled rail systems), this ball guide rail can be tailored to meet specific length requirements based on the formula provided by Bosch Rexroth. The permissible ambient temperature range for operation extends from -10°C to +80°C, accommodating a wide spectrum of working conditions. Overall, the Bosch Rexroth B.GUIDE RAIL CS offers robust construction with its carbon steel build, precise movement control due to its ultra-precision accuracy class, and versatile application potential through its protective features and ease of assembly design.
