BALL NUT FEM-E-B 12X10RX2-2

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FEM-E-B 12X10RX2-2 (R153249006) is a high-precision ball screw assembly designed for linear motion applications. This product features a single nut with a flange, belonging to the Miniature series and is specifically engineered to provide smooth, accurate, and efficient movement. The nominal diameter of the screw is 12 mm with a lead (P) of 10 mm, indicating the distance the nut will move with one revolution of the screw. This right-hand lead screw has a ball diameter (Dw) that works in conjunction with the number of ball track turns (i) to facilitate movement. The FEM-E-B 12X10RX2-2 comes with standard seals and standard axial clearance, ensuring reliable operation under various conditions. It has been constructed to Rexroth's connection dimensions for flange type B and is preloaded in class C for sizes excluding 12x3 and 12x5, which offers reduced backlash for improved precision. The tolerance grade for this model falls under T3, ensuring high accuracy in its performance. This ball screw assembly can operate within a temperature range from -10°C up to +80°C continuously, handling temporary peaks up to +100°C as measured on the outer shell of the nut. Its dynamic load capacity is specified by Bosch Rexroth for tolerance grade T3 only; if other grades are used, a correction factor must be applied as detailed in their technical notes. With its compact size L and nominal size designation of 12 x R x 2-2, this product is suitable for small-scale applications requiring meticulous control and reliability. The maximum permissible linear speed (vmax) and static load rating are also provided by Bosch Rexroth under specific conditions outlined in their general technical information. In summary, the Bosch Rexroth FEM-E-B 12X10RX2-2 is an advanced ball screw assembly designed for precise linear movements in compact applications while maintaining robustness through its design and engineering standards.
