BALL NUT SEM-E-C 32X5RX3,5-4

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SEM-E-C 32X5RX35-4 (R151231075) is a high-precision ball screw assembly designed for a variety of applications requiring accurate linear motion. This adjustable preload single nut SEMEC is engineered for optimal performance with a nominal diameter and right-hand lead direction, ensuring compatibility with standard mounting dimensions similar to DIN flange type C. The SEM-E-C 32X5RX35-4 features a standard seal and standard axial clearance, with a ball diameter that works in conjunction with the number of ball track turns to facilitate smooth movement. The product boasts an adjustable preload system and comes in tolerance grade T, which aligns with the specifications provided in the General Technical Notes and Information for screws. It has been crafted to work within an operating temperature range of -10°C to +100°C, capable of handling continuous operation at temperatures up to 80°C and temporary peaks up to 100°C as measured on the nut's outer shell. With its dynamic load capacity and static load rating defined for tolerance grades T3 and T5, this ball screw assembly is equipped to sustain significant loads during operation. Users must refer to the correction factor f_ac when dealing with other tolerance grades. The SEM-E-C 32X5RX35-4 also specifies a maximum permissible linear speed, ensuring that it can accommodate the demands of various high-speed applications. This Bosch Rexroth product comes as a zero-clearance adjustable single nut type under the SEMEC category, part of Productgroup ID Screw drive version drive type Ball screw assembly. It includes hole pattern BB for installation purposes. With its weight specified at 0.7 kg and nominal size detailed as 32 x 5 R x 35, this ball screw assembly is poised to deliver reliable precision in linear motion tasks while maintaining its structural integrity over time.
