BALL NUT SEM-E-C 16X16RX3-3

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SEM-E-C 16X16RX3-3 (R151206055) is a high-precision ball screw assembly designed for applications requiring meticulous motion control and positioning. This adjustable preload single nut SEMEC is engineered with a nominal diameter of 16 mm and a lead of 16 mm, indicating the linear distance traveled per one screw revolution. It features a right-hand thread direction, which is standard for most screw drives. The SEM-E-C 16X16RX3-3 boasts mounting dimensions similar to DIN 69051, Part 5, with a flange type C that ensures compatibility with a wide range of installations. The inclusion of standard seals and standard axial clearance makes this product suitable for various operating environments while maintaining its performance integrity. With an emphasis on accuracy and reliability, the SEM-E-C 16X16RX3-3 operates within a dynamic load capacity that is specified for tolerance grades T7 and T9. Users must refer to correction factors for other tolerance grades as outlined in the product's technical notes. The static load rating further underscores its capability to handle loads without compromising motion precision. This ball screw assembly can operate effectively within a temperature range of -10°C to +80°C, accommodating continuous use at temperatures up to +80°C with temporary peaks permissible up to +100°C. These temperature parameters are measured on the outer shell of the nut, ensuring that the unit's thermal characteristics are well-defined for project planning. The SEM-E-C 16X16RX3-3 has been designed as a zero-clearance adjustable single nut, part of Bosch Rexroth's Standard series, offering users the ability to fine-tune preload settings for optimal system rigidity and minimizing backlash. Its ball screw assembly format delivers smooth and efficient motion transfer from rotary to linear movements. In summary, the Bosch Rexroth SEM-E-C 16X16RX3-3 (R151206055) represents an advanced solution in precision motion control with its robust design tailored for demanding applications that require exacting standards in positioning accuracy and operational reliability.
