BALL NUT FEM-E-B 40X20RX6-3

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FEM-E-B 40X20RX6-3 (R150247083) is a high-precision ball screw assembly designed for linear motion applications. This single nut with flange FEMEB is engineered with a nominal diameter of 40 mm and a lead of 20 mm, featuring a right-hand thread direction. It has a ball diameter of Dw and includes multiple ball track turns for efficient motion transfer. The mounting dimensions are similar to DIN 69051, Part 5, flange type B, ensuring compatibility with standardized components. This model comes equipped with standard seals and standard axial clearance, providing reliable operation and maintenance ease. It offers preload classes ranging from C0 to C5 and a tolerance grade of T3 for sizes as per the product overview for screws. The dynamic load capacity C and static load capacity C0 are valid for tolerance grades T3 and T5 only; correction factors must be considered for other grades as specified in the technical notes. The FEM-E-B 40X20RX6-3 operates within a temperature range of -10°C to +100°C, allowing for continuous use at temperatures up to 80°C with temporary peaks up to 100°C as measured on the nut's outer shell. Its maximum permissible linear speed is noted in the characteristic speed section of the technical notes. Constructed for durability, this ball screw assembly boasts an impressive static load rating and dynamic load capacity that ensure it can handle significant loads without compromising performance. Its design includes a hole pattern BB and comes in various sizes denoted by Size D g, Size d, Size L1, Size L2, etc., offering flexibility in application requirements. Weighing approximately .kg for its nominal size of 40 x R x 20 mm, the Bosch Rexroth FEM-E-B 40X20RX6-3 provides an ideal solution for those needing precise linear motion control in their machinery or equipment setups.
