BALL NUT FEM-E-B 16X10RX3-3

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FEM-E-B 16X10RX3-3 (R150204083) is a high-precision ball screw assembly designed for linear motion applications. This single nut with flange model features a nominal diameter of 16 mm and a lead of 10 mm, adhering to the right-hand thread standard. It is equipped with standard seals and standard axial clearance to ensure optimal performance in various conditions. The FEM-E-B 16X10RX3-3 boasts mounting dimensions similar to DIN, with flange type B for easy integration into existing systems. The product has been engineered with a dynamic load capacity that is specified for tolerance grades T7 and T5; for other tolerance grades, users must refer to the provided correction factor. The nut falls under preload classes C0 to C5 and tolerance grade T, ensuring precise movement and reduced backlash. This ball screw assembly can operate within a temperature range from -10°C to +80°C continuously, with temporary peaks up to +100°C as measured on the nut's outer shell. It supports a maximum permissible linear speed (vmax) that should be noted in the technical documentation for safe operation. Constructed for durability and reliability, this Bosch Rexroth screw drive nut is part of their standard series and is categorized under Productgroup ID A. It offers an impressive static load rating and can accommodate high-speed applications without compromising on performance or lifespan. In summary, the Bosch Rexroth FEM-E-B 16X10RX3-3 ball screw assembly is an advanced component that delivers precise linear motion control in demanding applications. Its robust design ensures long-term reliability while maintaining high levels of accuracy and efficiency in mechanical systems.
