LINEAR CARRIAGE MKK-080-CR-LSS-XX-TL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-080-CR-LSS-XX-TL1 (R117310761) is a state-of-the-art linear module designed for high precision and compactness. This ready-to-install system features an aluminum profile with integrated ball rail systems, providing a highly rigid and accurate guide for various applications. The carriage itself is made of aluminum, offering T-slots or threaded holes for flexible mounting options, along with centering holes to ensure precise alignment. The MKK-080-CR-LSS-XX-TL1 employs a precision ball screw assembly (BASA) in rolled design, with an option for tolerance grades T5 or T7 according to ISO standards. This ensures zero-clearance operation and high thrust capabilities with maximum lengths up to Lmax. For protection and maintenance ease, the module includes sealing strips—plastic for the MKK series or corrosion-resistant steel strips for other models—and supports individual lubrication connections compatible with one-point lubrication systems. The integrated measuring system (IMSA) offers significant advantages by requiring no additional space and eliminating measurement inaccuracies through full integration into the guide system. It simplifies maintenance by allowing individual component replacement without complex tuning. Material options include ALST, featuring anodized aluminum frames and anti-friction bearing steel components, or ALCR, which provides additional corrosion resistance with hard chrome plating. Lubrication variants such as LSS provide factory initial lubrication suitable for standard conditions, while other options like LPG offer corrosion prevention without initial greasing. Additionally, the MKK-080-CR-LSS-XX-TL1 can be outfitted with various attachments like proximity switches, mechanical switches, cable ducts made of aluminum profile, clamping fixtures, and sliding blocks. The screw support SPU enhances performance by allowing high-speed operation over long lengths up to 5800 mm while being maintenance-free and optionally sealed. This linear carriage is designed for applications demanding high positioning accuracy and repeatability along with robust thrust force handling. It caters to a wide range of uses where precise linear motion is essential.
