LINEAR CARRIAGE MKK-080-ST-LPG-XX-SL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-080-ST-LPG-XX-SL1 (R117310758) is a state-of-the-art linear module that is part of the new product generation MKXXXXNN. This module offers a compact and ready-to-install guide system that integrates an aluminum profile with Rexroth Ball Rail Systems for precision and high-performance operation. The carriage itself is constructed from aluminum, featuring either T-slots or threaded holes for attachments, as well as centering holes. It is driven by a precision Ball Screw Assembly (BASA) in a rolled design, which can be selected in tolerance grade T5 or T7 according to ISO standards, ensuring clearance-free movement. The LINEAR CARRIAGE MKK-080-ST-LPG-XX-SL1 is designed without initial factory lubrication but with corrosion prevention measures in place. Users must apply basic lubrication upon installation. The unit's structural elements include an extremely compact frame, carriages, and end blocks made of anodized aluminum (AL), while the Ball Guide Rail, Ball Runner Block, and BASA are crafted from anti-friction bearing steel (ST). For applications requiring corrosion resistance, certain components feature a corrosion-resistant coating. This linear module boasts an integrated measuring system called IMSA that requires no additional space and avoids inaccuracies due to parallelism offset between the measuring system and the guide system. The measuring components are fully integrated into the guide system for ease of maintenance and replacement. In terms of attachments and accessories, this model supports proximity or mechanical switches, cable ducts made from aluminum profiles, clamping fixtures, sliding blocks, connecting shafts, and connection technology for Linear Motion Systems. For product generation MKXXXXNN only: magnetic field sensors can be directly mounted onto the profile body without additional attachments. The structural design ensures high positioning accuracy and repeatability as well as the capability to handle high thrust forces. The LINEAR CARRIAGE MKK-080-ST-LPG-XX-SL1 is suitable for various applications where precise linear motion is required.
