LINEAR CARRIAGE MKK-080-ST-LCF-XX-TL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-080-ST-LCF-XX-TL1 (R117310713) represents a state-of-the-art linear module system from the new product generation MKXXXXNN, designed for high precision and compactness. This linear carriage features an extremely compact aluminum profile with integrated Rexroth Ball Rail Systems, ensuring precise and ready-to-install guide systems. The carriage is constructed from aluminum and offers options for T-slots or threaded holes, along with centering holes for versatile mounting solutions. Equipped with a precision Ball Screw Assembly (BASA) in a rolled design, this model provides high-performance motion control with the option of zero-clearance due to its cylindrical single nut. It adheres to ISO tolerance grades T or T5 and supports long travel distances up to 5400 mm, thanks to its screw support SPU which ensures stable operation even at high speeds. The LINEAR CARRIAGE MKK-080-ST-LCF-XX-TL1 is prepared for connection to central lubrication systems using liquid grease or oil, allowing for easy maintenance and longevity of the system. It uses lithium-based high-performance grease according to DIN standards, ensuring reliable operation under normal environmental conditions. This module also includes an integrated measuring system IMSA which eliminates the need for additional space or complex mounting procedures. The measuring system is fully integrated into the guide, providing accurate position measurement without inaccuracies caused by parallelism offset. For attachment options, this linear module offers a comprehensive accessories program including sensors, cables, clamping fixtures, sliding blocks, connecting shafts, and connection technology compatible with Linear Motion Systems. Furthermore, it is designed with various sealing options like plastic strips for the MKK series or corrosion-resistant steel strips for enhanced durability. Overall, the Bosch Rexroth LINEAR CARRIAGE MKK-080-ST-LCF-XX-TL1 is engineered to deliver precision motion control in compact dimensions suitable for a wide range of applications requiring accurate positioning and repeatability along with high thrust forces.
