LINEAR CARRIAGE MKK-065-CR-LPG-XX-SL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-065-CR-LPG-XX-SL1 (R117300766) is a state-of-the-art linear module system that exemplifies the latest advancements in guide systems with its precise, ready-to-install features and compact dimensions. This model is part of the innovative MKXXXXNN product generation which has been meticulously enhanced for performance while maintaining backward compatibility. The structural design of the MKK-065-CR-LPG-XX-SL1 boasts an extremely compact aluminum profile incorporating a Rexroth Ball Rail System. The carriage itself is constructed from aluminum and can be customized with either T-slots or threaded holes, complete with centering holes for precise alignment. The module is driven by a precision Ball Screw Assembly (BASA) in a rolled design, and customers can select from tolerance grades T5 or T7 according to ISO standards. A standout feature of this model includes individual lubrication versions for easy connection to one-point lubrication systems. For protection and maintenance, the unit comes with sealing strips made of plastic for the MKK series, ensuring long-term durability and performance. Additionally, the screw support SPU offers benefits such as maintenance-free operation and high-speed capabilities over lengths up to 5400 mm. The LINEAR CARRIAGE also integrates an IMSA measuring system that eliminates external mounting requirements and potential inaccuracies due to parallelism offsets. It allows for full integration without complex mounting or tuning work. Material pairing options include ALST and ALCR variants, where components are crafted from anodized aluminum with antifriction bearing steel or corrosion-resistant coatings depending on the choice. Lubrication variants range from factory initial lubrication (LSS), corrosion prevention without initial lubrication (LPG), preparation for central liquid grease systems (LCF), to oil-based central lubrication systems (LCO). This Bosch Rexroth linear module is designed for high positioning accuracy, repeatability, and thrust forces with its integrated Ball Rail System and Ball Screw Assembly. It provides flexible motor mounting options through timing belt side drives or flanged-type couplings. Additionally, it comes equipped with proximity switches or mechanical switches, cable ducts made of aluminum profiles, clamping fixtures, sliding blocks, connecting shafts, connection technology for Linear Motion Systems, sensors, extension cables as well as sealing strips or bellows cover options depending on the size of the module. In summary, this linear carriage system from Bosch Rexroth offers unmatched precision in movement control applications where space constraints are a consideration without compromising on performance features or customization possibilities.
