LINEAR CARRIAGE MKK-065-ST-LCF-XX-TL1

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR CARRIAGE MKK-065-ST-LCF-XX-TL1 (R117300713) represents the latest evolution in linear motion technology, showcasing enhanced performance features while maintaining compatibility with previous series. This ready-to-install linear module is characterized by an extremely compact aluminum profile that incorporates the Rexroth Ball Rail System. The carriage, crafted from aluminum, offers versatile mounting options with T-slots or threaded holes and includes centering holes for precise alignment. Equipped with a precision ball screw assembly (BASA) in a rolled design, the module achieves high accuracy and is available in ISO tolerance grades T5 or T7. The carriage ensures zero-backlash motion via a cylindrical single nut and is protected by sealing strips—plastic for the MKK range and corrosion-resistant steel for higher models. The product supports high speeds over lengths up to 5400 mm, thanks to the optional screw support SPU, which aids in horizontal applications and ensures maintenance-free operation. For automation tasks requiring exact positioning, this linear carriage integrates an IMSA measuring system that eliminates inaccuracies due to parallelism offset between the guide and measuring systems. It allows individual components like the Runner Block, Scanner, and Guide Rail with scale to be serviced separately. The material pairing options include ALST or ALCR variants for different environmental resistances. Lubrication variants range from factory-applied initial lubrication (LSS), preparation for central lubrication systems with liquid grease (LCF), oil (LCO), or basic corrosion prevention without initial lubrication (LPG). Additionally, this module supports a wide range of attachments such as sensors, cables, clamping fixtures, connecting shafts, and more—all designed to facilitate integration into various Linear Motion Systems. For motor attachment, it offers options such as timing belt side drive or flanged-type coupling. In summary, the Bosch Rexroth LINEAR CARRIAGE MKK-065-ST-LCF-XX-TL1 is a highly precise and adaptable linear motion solution that provides robust performance for demanding automation applications.
