END BLOCK FIXED B. MKK-080-NN-3 BG

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth END BLOCK FIXED B. MKK-080-NN-3 (R117210720) is a high-performance linear module from the advanced MKXXXXNN product generation, designed for precision and compactness. This ready-to-install module can be customized to any length up to the maximum specified (Lmax), and features an extremely compact aluminum profile with an integrated Rexroth Ball Rail System. The carriage is constructed from aluminum and offers the option of T-slots or threaded holes for versatile attachment possibilities, as well as centering holes for precise alignment. This model boasts a precision Ball Screw Assembly (BASA) with a rolled design, available in ISO tolerance grades T5 or T7 with zero-clearance cylindrical single nuts. It also includes sealing strips made from plastic for the MKK series, while corrosion-resistant steel strips are used for other models within the same series. The END BLOCK FIXED B. MKK-080-NN-3 incorporates a screw support system (SPU) that enhances performance in horizontal applications and allows speeds over long lengths of up to 7000 mm without maintenance requirements. Additionally, it features an Integrated Measuring System (IMSA) that eliminates inaccuracies caused by misalignment between measuring systems and guide rails, ensuring precise measurements without requiring additional space or complex installation procedures. In terms of material pairing, customers can choose between ALST and ALCR options depending on their requirements for corrosion resistance and structural composition. Lubrication variants include LSS (initial factory lubrication), LPG (corrosion prevention without initial lubrication), LCF (prepared for central liquid grease lubrication systems), and LCO (prepared for central oil lubrication systems). The module's accessories program offers a range of components including sensors with extension cables, switching lugs, cable ducts made from aluminum profiles, clamping fixtures, sliding blocks, connecting shafts, and connection technology suitable for various linear motion systems. The carriage design accommodates either thread or T-slot attachments while offering protections such as sealing strips or bellows covers depending on the model. Overall, the Bosch Rexroth END BLOCK FIXED B. MKK-080-NN-3 represents a versatile solution equipped with top-tier components ensuring high positioning accuracy, repeatability, and thrust forces suitable for diverse applications requiring precise linear motion control.
