LINEAR-SET LSADR1T-40-WV-1200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSADR1T-40-WV-1200 (R109924087) is a high-precision linear motion system designed for applications requiring smooth and accurate guidance with resistance to torsional loads. The set includes a lightweight precision tandem housing made of aluminum, which houses two torque-resistant linear bushings. These bushings are paired with a precision steel shaft featuring a single ball guide groove, ensuring precise linear movement. The shaft diameter is standardized as per the provided table, and the set comes without external seals, emphasizing its suitability for environments where such protection is not critical. The bearing plates are made of hardened steel and are pre-set to zero clearance by the manufacturer to guarantee optimal load distribution and minimal play in the system. This linear set is capable of handling dynamic loads effectively due to its robust design that includes relubrication capabilities, extending the life cycle of the components under motion. The product can withstand a range of ambient temperatures, making it versatile for various operational conditions. It also boasts an impressive dynamic torsional moment load capacity, ensuring stability against cocking loads. With its tandem format (Type T) of linear bushings, this Bosch Rexroth linear set provides enhanced load capacity when both bushings are under equal load—both in terms of dynamic and static capacities. It’s designed to accommodate maximum accelerations and permissible linear speeds without compromising performance or integrity. This product is part of Productgroup ID E indicating its series and size classification within Bosch Rexroth's lineup of linear motion products. Its mass is optimized for efficiency without sacrificing strength or durability. The LINEAR-SET LSADR1T-40-WV-1200 stands out as an excellent choice for designers seeking reliable and maintenance-friendly components for sophisticated linear motion applications.
