LINEAR-SET LSSDR1T-16-WV-1200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-16-WV-1200 (R109721687) is a comprehensive linear motion set designed for precision applications requiring high rigidity and resistance to torque loads. This set comprises a precision steel shaft with a diameter of 16 mm and a standard length of 1200 mm, which features one ball guide groove for smooth movement. The shaft comes with two torque-resistant linear bushings that are pre-set to zero clearance by the manufacturer, ensuring optimal performance and stability against cocking loads right from installation. The LINEAR-SET is characterized by its torquetransmitting, hardened steel bearing plates and its ability to handle dynamic load capacities efficiently. The product is designed without external seals, making it suitable for environments where additional sealing is not required. Its tandem ball guide grooves enhance the system's load capacity when both linear bushings are under equal load, providing minimal values as the direction of loading might vary. This model boasts an impressive dynamic torsional moment load capacity (Mt), highlighting its capability to withstand high torsional forces while maintaining precision. The product operates effectively within a permissible ambient temperature range, ensuring reliability in varying working conditions. It also features an outer diameter (D) that supports maximum linear speeds (vmax), contributing to the system's overall efficiency. With its substantial mass (m kg/m), this LINEAR-SET provides the necessary heft for stable operation in demanding applications. It falls under the product group ID designated for linear sets with linear bushings in tandem format (T), signifying its specialized design for applications where high load capacity and resistance to torsional moments are essential. In summary, the Bosch Rexroth LINEAR-SET LSSDR1T-16-WV-1200 is an advanced solution for those seeking robust performance in linear motion systems without the need for external sealing mechanisms. Its precise engineering ensures reliable operation under various loads and environmental conditions, making it an ideal choice for sophisticated mechanical setups requiring high levels of accuracy and durability.
