LINEAR-SET LSSDR1T-16-WV-400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-16-WV-400 (R109721680) is a high-precision linear motion set designed to provide reliable and accurate guidance for various applications. This product features a precision steel shaft with a diameter of 16 mm and a standard length, accompanied by two torque-resistant linear bushings in a tandem arrangement for enhanced load distribution. The shaft includes one ball guide groove, ensuring smooth motion and increased rigidity. The LINEAR-SET LSSDR1T-16-WV-400 is crafted from standard steel and comes without external seals, making it suitable for environments where additional sealing is not required. The bearing plates are made of hardened steel and are pre-set to zero clearance by the manufacturer, which contributes to the system's high stability against cocking loads. This linear set is part of the Series Torque Size E, which signifies its capacity to withstand dynamic torsional moment loads effectively. It has been engineered to operate within an ambient temperature range of -20°C to +80°C, ensuring consistent performance across various working conditions. The outer diameter D of the set allows for maximum permissible linear speeds, while the dynamic load capacity C indicates the minimal values under equal load conditions on both bushings. Furthermore, this product boasts an impressive dynamic load rating and static load capacity, which are indicative of its robustness in both moving and stationary applications. The mass m/kgm specification provides information on the weight of the unit, an important consideration for design and transportation. Overall, the Bosch Rexroth LINEAR-SET LSSDR1T-16-WV-400 (R109721680) represents a sophisticated solution for linear motion requirements that demand precision, durability, and resistance to torsional forces in tandem configurations without the need for external sealing.
