LINEAR-SET LSGF-B-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-B-30-DD (R108183040) is a high-precision linear motion component designed for a wide range of applications requiring accurate and smooth linear movement. This linear set is comprised of a flanged housing made from lamellar graphite cast iron, which ensures durability and rigidity, and a super linear bushing B without a self-alignment feature. It is specifically tailored for applications with a vertical shaft orientation. The set includes two retaining rings and two additional spacer rings made from steel, designed to fit shaft diameters with precision. Integrated wiper seals on both sides maintain cleanliness within the system by preventing the ingress of contaminants, thereby extending the service life of the unit. The radial clearance is non-adjustable, and this model comes without initial lubrication, allowing users to apply lubrication best suited for their specific application. With a static load rating C0 and dynamic load capacity C1, this linear set can handle significant loads while maintaining smooth motion. The friction force F_R is noted for its low drag under no radial load conditions, which contributes to efficient operation at varying speeds. The permissible ambient temperature ranges from -20°C to +80°C, making it suitable for use in various working environments. The LINEAR-SET LSGF-B-30-DD has an outer diameter D1 size E and an L size L1, ensuring compatibility with corresponding components. Moreover, it can achieve maximum permissible linear speeds (vmax) up to 5 m/s; however, service life may be limited by increased wear on plastic parts at such speeds. Tests have indicated that total travel can range between 100x10^3 m to 200x10^3 m without failure. This product has a weight of 0.5 kg and is part of Bosch Rexroth's product group ID which includes various configurations of linear sets with bushings and shafts in flange formats. It's engineered as a modular unit that seamlessly integrates into existing Linear Set series assemblies or new designs requiring precise vertical motion control.
