LINEAR-SET LSGF-M-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGF-M-25-DD (R108122500) is a high-quality linear set made of steel with a flange design, tailored for precise linear motion applications. This set includes a standard LB metal linear bushing equipped with wiper seals, ensuring clean operation by preventing the ingress of contaminants. The flanged housing is constructed from lamellar graphite cast iron, offering robust support and alignment for the system. Designed for ease of installation, this linear set comes with two retaining rings and additional spacer rings made of steel, suitable for shaft diameters, providing a secure fit and maintaining the integrity of the setup. The radial clearance is not adjustable, but the standard h shaft radial clearance ensures similar values to those specified in the hH column under Radial clearance for R standard linear bushings. This product operates efficiently within a permissible ambient temperature range of -20°C to +80°C. It boasts an impressive dynamic load capacity and static load rating that are minimal values due to potential variations in loading orientation and direction. The LINEAR-SET LSGF-M-25-DD ensures low frictional drag under no radial load conditions, which varies with speed and lubrication levels. The set's size V corresponds to its foot dimensions while size E denotes its outer diameter. It features a breakaway force that guarantees smooth initiation of movement and supports a maximum permissible linear speed vmax. Weighing in at just 1 kg, this linear guide system promises both lightweight design and robust performance. Overall, the Bosch Rexroth LINEAR-SET LSGF-M-25-DD is an optimal solution for vertical shaft designs requiring precise guidance and reliable operation in various industrial applications where contamination exclusion and durability are paramount.
