LINEAR-SET LSGE-M-40-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGE-M-40-DD (R106624000) is a high-precision linear motion set designed for various applications requiring smooth and accurate linear movement. This set features a standard linear bushing with wiper seals, which are integrated to ensure cleanliness and longevity of the system by preventing the ingress of contaminants. The bushing is made from durable steel and comes with two retaining rings, providing robust performance and reducing maintenance requirements. With an adjustable design, this linear set allows for zero-clearance or preload adjustments, enhancing the precision of motion control in your assembly. The shaft diameter 'd' ensures compatibility with corresponding equipment, while the normal precision housing made from lamellar graphite cast iron offers a stable and reliable base for the bushing. The LINEAR-SET LSGE-M-40-DD is equipped to handle dynamic loads with its specified dynamic load capacity 'C', ensuring it can support minimal values even when the orientation and direction of loading are not clearly defined. Similarly, the static load rating 'C' indicates its ability to withstand stationary forces without deformation or failure. Operating within a permissible ambient temperature range, this linear set can adapt to various working environments without compromising on performance. Its design includes a friction force feature that indicates the resistance encountered during motion without radial load—this factor is vital for calculating energy efficiency and operational smoothness. Furthermore, the product comes clamped to an 'h' shaft lower limit and is set to zero-clearance by default, simplifying installation processes. The outer diameter 'D', breakaway force, maximum permissible linear speed 'vmax', radial clearance specifications, weight, and size dimensions such as Size V, Size B, Size E, Size H, Size L, and Size SW are all meticulously crafted to meet standard requirements and ensure seamless integration into your system. Overall, the Bosch Rexroth LINEAR-SET LSGE-M-40-DD offers a reliable solution for achieving precise linear motion in various industrial applications without compromising on durability or adjustability.
