LINEAR-SET LSG-A-12-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-A-12-DD (R106561240) is a high-quality linear motion set designed for precision applications requiring smooth and accurate guidance. This product features a closed linear bushing of size V from the Super A series, which includes an integrated self-alignment feature that enhances movement accuracy and reduces installation time. The set is comprised of a steel linear set with two seals, ensuring durability and protection against contaminants. The lamellar graphite cast iron housing provides a sturdy foundation for the super linear bushing A, which operates with a standard precision level. The shaft diameter 'd' is engineered for fixed working bore diameters, facilitating straightforward installation. Integrated wiper seals on both sides of the bushing minimize frictional drags when not under radial load, though these frictions can vary depending on speed and lubrication conditions. The LINEAR-SET LSG-A-12-DD boasts an impressive dynamic load capacity (C), tailored to withstand the main direction of loading. Should loading occur in other directions, the load capacities can be adjusted by applying specific factors detailed in the product specifications. This set can handle maximum accelerations (amax) and operate within ambient temperatures ranging from -20°C to +80°C without performance degradation. With an outer diameter (D) designed to accommodate various applications, this product also specifies breakaway force requirements and maximum permissible linear speeds (vmax), with potential speeds reaching up to 5 m/s. However, it's important to note that at such high speeds, service life may be reduced due to increased wear on plastic components. This Bosch Rexroth linear set has been tested extensively, indicating total travel distances ranging from 100 km to 1000 km without failure under specified conditions. The static load rating (C0) ensures stability under stationary loads, while the weight of 0.3 kg makes it suitable for various industrial applications requiring precise linear movement. The LINEAR-SET LSG-A-12-DD is an ideal choice for those seeking reliable performance in their linear motion systems.
