LINEAR-SET LSG-M-80-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-M-80-DD (R106528000) is a high-precision linear motion system designed to provide smooth and accurate linear movement in a variety of applications. This linear set is constructed from durable steel and features a closed design with standard LB metal for enhanced performance and longevity. It includes a precision housing made of lamellar graphite cast iron steel, ensuring stability and resistance to wear. This model comes equipped with standard linear bushings that incorporate wiper seals on both sides, which serve to protect against contaminants while maintaining lubrication integrity. The inclusion of two retaining rings ensures secure positioning and operation within the system. The shaft diameter 'd' is meticulously crafted to maintain the radial clearance as indicated by the h shaft specification, providing similar radial clearance values as specified under the Radial clearance for the R standard linear bushing. The LINEAR-SET LSG-M-80-DD boasts impressive mechanical specifications including a dynamic load capacity C, which signifies minimal values due to varying orientations and loading directions that cannot always be clearly defined. It also has a static load rating C that indicates minimal values for similar reasons. The system is capable of withstanding maximum accelerations (amax) and operates within a permissible ambient temperature range, ensuring reliability in diverse environmental conditions. Furthermore, this linear set has been designed to handle breakaway forces efficiently and can operate at maximum permissible linear speeds (vmax), making it suitable for high-speed applications. The friction force FR reflects the drag generated by the bushings when not under radial load, influenced by speed and lubrication conditions. Overall, the Bosch Rexroth LINEAR-SET LSG-M-80-DD provides robust performance with its well-engineered components, making it an excellent choice for those seeking reliable linear motion solutions without compromise on precision or durability.
