LINEAR-SET LSG-M-50-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSG-M-50-DD (R106525000) is a meticulously engineered linear motion system designed to provide precise and smooth linear movement in various applications. This product is part of the LINEAR-SET series, which integrates high-quality linear bushings and shafts to facilitate reliable guidance and support for moving parts. The LSG-M-50-DD model features a closed configuration with two seals, ensuring protection against contaminants and extending the service life of the set. Constructed with a robust steel shaft of diameter 'd' and precision housing made from lamellar graphite cast iron, this linear set offers durability and stability. It includes standard LB metal bushings with wiper seals that minimize friction while maintaining the cleanliness of the system by preventing the ingress of dust and debris. The two retaining rings included in the design further enhance its structural integrity. This Bosch Rexroth linear set is characterized by its standard precision, which ensures consistent performance across various applications without sacrificing accuracy. It comes with an h shaft radial clearance, calculated based on working bore diameter and shaft tolerance statistics, offering similar radial clearance values as those specified under Radial clearance for the R standard linear bushing. The dynamic load capacity C indicates minimal values since load orientation and direction can vary; however, these capacities are assured to be at least at specified minimal thresholds. The static load rating C also reflects minimal values due to varying loading conditions but guarantees a baseline level of performance. With a maximum permissible ambient temperature range indicated in degrees Celsius, this product can operate effectively within designated thermal conditions. The outer diameter D, breakaway force, maximum permissible linear speed vmax, friction force, and weight specifications are all defined to ensure that users can select this model for their specific requirements confidently. In summary, the Bosch Rexroth LINEAR-SET LSG-M-50-DD (R106525000) represents a high-quality solution for applications requiring reliable linear motion control with minimal maintenance needs due to its durable construction and integrated sealing features.
